Analog In/Out
The module facilitates integration using voltage and current analog signals.
SKU: MUL-211-D-01
EAN: 5902983719175
DIN rail
TF Bus
These analogue signals enables integration of various devices and sensors in an intelligent home (e.g. temperature control, humidity control, wind speed control, light intensity control).
Properties
- support for 0-10V, 0-5V analog standards
- support for 0-20 mA current sensors
- support for 1-Wire technology
TECHNICAL INFFORMATION
DC power supply:
24 V
maximum power consumption:
0.48 W
maximum device current (@24V):
20 mA
maximum wire cross section:
1.5 mm²
maximum input voltage for IN1-4:
10 Vdc
maximum input voltage for IN5-6:
5 Vdc
maximum output voltage for OUT1-4:
10 Vdc
maximum number of supported 1-wire sensors:
16
maximum output current for OUT1-4:
10 mA
weight:
105 g
size (DIN):
4
dimensions (h/w/d):
58/71/90 mm
operational temperature range:
0 – 45 °C
